I’m going to upgrade an Epiphone DOT Studio that I recently picked up and I’ll be putting two additional POTs in.. I have a request, would you please send me a link to your wiring diagram and would you PLEASE make a crude template showing where your POT and selector switches are positioned in relationship to each other on the guitar? I want the installation to look as stock (personal use but…) as possible. Thought about going to GC and making one but didn’t think they’d appreciate me pulling off the knobs. Haven’t been able to find a template in three days of searching 🙂 Thanks again
My 2012 series on DIY Guitar Pedal building continues to draw visitors to planetz. I just went through and updated a few stale links, and I noticed that I never really posted entire table of contents for the series. So here it is. I also added these links to the top of each page. Better late than never!
- Intro to DIY Pedal Building
- Beginner’s Course in Sketchup, Modeling a 125B Guitar Pedal Enclosure
- Drilling a 125B Guitar Effects Pedal Enclosure
- Pedal Enclosure Finishing: Surface Prep, Priming and Painting
- Using GIMP to Create Pedal Artwork
- Printing and Applying Waterslide Decal to Pedal Enclosure
I also made a youtube playlist: DIY Guitar Pedal Building
I was super-excited to get my new Blackstar Stage 60 earlier this month. But immediately after plugging in and firing it up for the first time, I noticed some strange noise issues. I plugged the guitar in directly, with no other pedals and no effect loop. On all 3 channels, I heard some very obvious gungy badness on certain notes. The problem was not evident when listening through the speaker emulated output. More
My pedal board is flush with overdrives, but sorely lacking in distortion. I’ve never loved my RAT – it has scurried on and off my pedalboard over the years, never finding a permanent home there. I’ve really been needing a solid traditional distortion lately, to use with my band covering tunes by Green Day, Blink-182, Weezer, etc.
I love my Vox Ice-9 overdrive, so I decided to try out the Vox Satchurator. It’s apparently a boutiquey version of the classic Boss DS-1. When I received it, I immediately plugged in and lost myself in its glorious tones for an hour or so. It sounds really really good. Very different from my overdrives and fuzz. It has a big, saturated, overtone-rich distortion. Excellent for thick heavy leads, but also equally good for massive chunky rhythm. More
As I mentioned previously, my pedal board’s power supply died, so I’ve been temporarily using an old Korg 9V power supply.
I’ve been getting some hum from Ryan’s Fulltone Fat-Boost, and finally decided to do some sleuthing to figure out why.
Fortunately, before I even cracked open the Fat-Boost, I hooked up a multimeter to measure the voltage output of the Korg supply, and it turns out that this little guy is really putting out 13V, not 9V. Well, that’s annoying. Is it mislabeled, or just over-compensating for something? More
After a bit of trial and error, it was clear that my ancient SKB PS-25 pedalboard power supply had finally keeled over. I never use batteries, but fortunately a couple of the pedals had old 9V batteries still in them, so it was enough to scrape by for the rehearsal.
Hey, here’s the power supply for my Digitech Jamman Delay which I’m not currently using in my live rig. It says 9V, 1.3A. Strange, it doesn’t show a polarity, but it’s a power supply for a guitar pedal, and the plug barrel fits, so it must be good, right? What could possibly go wrong?
In this article, Pete Biltoft at Vintage Vibe Guitars gives an in-depth explanation of pickup coil wiring options. Note this information is provided in the context of humbuckers, but applies just as well to a pair of single coil pickups that are RWRP relative to each other. You may also find my earlier posts useful: Humbucker Wiring and Coil Splitting, and Pete’s previous article on Coil Splitting/Tapping.
Thanks again to Pete for the permission to post this here!
In this Tech Tips newsletter I would like to discuss the wiring options possible with a single humbucking pickup which has a four conductor output cable with an independent ground lead.
The following information applies not only to conventional humbucking pickups with side by side coils, but also to stacked humbuckers and humbuckers in other size formats or configurations.
In this newsletter I do not plan to cover the details of wiring one or more switches to accomplish the possible coil configurations described below. A great deal of useful information on this topic is provided on the Stewart MacDonald website, the Guitar Nuts website and on www.deaf-eddie.net
First, let’s start with the basics:
